This ABE-102b 80A 2P thermal-magnetic moulded case circuit breaker (MCCB) is a 1:1 direct replacement for the original equivalent model. Manufactured in strict accordance with IEC 60947-2 (formerly IEC947-2) and GB 14048.2 standards, it is designed for low-voltage power distribution systems at 50/60Hz with rated operating voltage up to AC 380/415V.

It provides overload protection and short-circuit protection, as well as infrequent circuit switching. Rated as Category A circuit breaker, it is ideal for final and branch circuit protection.

Item	Specification
Model	ABE-102b 80A
Type	2-Pole (2P) Thermal-Magnetic MCCB
Frame current	100A
Rated current (In)	80A
Rated operational voltage (Ue)	AC 380/415V
Rated insulation voltage (Ui)	690–800V
Frequency	50/60Hz
Trip type	Thermal-magnetic (TMD)
Breaking capacity	Standard breaking type (b-curve)
Ultimate short-circuit breaking capacity (Icu at 380V)	Approx. 25–30kA
Utilization category	Category A
Mounting	Fixed, front connection
Operation	Manual handle operation
Ingress protection	IP20
Standards	IEC 60947-2, GB 14048.2

• Perfect direct replacement

  Fully matches the original ABE-102b 80A in dimensions, mounting holes, wiring and electrical performance. No modification needed — plug-and-play replacement.

• Reliable dual protection

  Thermal-magnetic tripping provides accurate long-delay overload protection and instantaneous short-circuit protection, quickly cutting off fault current to prevent equipment and circuit damage.

• Compliant & stable quality

  Produced under full IEC 60947-2 standards with strict factory testing. Excellent anti-interference, anti-aging and temperature resistance for industrial-grade reliability.

• Cost-effective alternative

  Offers original-equivalent performance at a more competitive price, ideal for maintenance, retrofit projects and bulk procurement.

• Easy installation & operation

  Compact structure, front wiring design, user-friendly manual operation, suitable for standard distribution cabinets.

 Applications

• Final and branch circuit protection in low-voltage power distribution systems
• Industrial machinery, control panels and automation equipment
• Commercial and residential power distribution rooms
• Renewable energy and power supporting systems
• Replacement and maintenance of original ABE-102b series breakers

Packaging & Service

• Standard industrial packaging with certificate of conformity and user manual
• Professional technical support for selection, installation and troubleshooting
• Reliable after-sales warranty
